Main machine components have adopted the structure of thermal symmetry and thin-walled main-stock with multi-layer ribs.

The main base parts of machine are made from high-grade high-quality gray casting iron with quenching trem-ent.

The use of special bearings on balls crew with pre-pull treatment and laser detective compensation.

The adoption of balance weight block with motion-based device has prevented the spindle from vibration when moving.

The strength and rigidity of millling machine is improved 50%.
The rigidity and stability of cutting feed are enhanced so as to improve
the machine processing accuracy and using life.

3 axis diven power is improved 30%.
Spindle motor driven power is improved more than 35%.

Sliding saddle is optimized changed to a thin-walled multi-ribbed box-type structure,making the sliding saddle rigidity increased 50%

The column structure is changed into large span, multi-ribs, thin-wall, box-shaped structure,the rigidity is increased more than 60%.

This series of milling machine configure a automatic screw-type chip conveyor to save time in chip removing.

Configure a strong chip washdown devices and a large chip removal ou-tlet, can cleaning up the troubled chip.

The machine standard with the armless type toll storage,faster tool change time, and compre-hensively improve the processing efficiency

CNC control system upgrade with 10.2-inch large screen, make the operation easier.

To meet all your needs

All Series of CNC Milling Machine

china cnc milling machine vmc for sale

vmc for sale

China cnc milling machine

Processing Case

china cnc milling machine

About Us

china cnc milling machine

Model No.	vmc for sale	NX-30	NX-36	NX-45
Capacity	X axis travel/mm	500	600	700
	Y axis travel/mm	300	360	450
	Z axis travel/mm		450	510
	Spindle nose to table surface/mm	90-540	150-600	150-660
	Spindle nose to column surface/mm	350	380	520
Feedrate	X,Y,Z rapid traverse/M/min	15/15/15	15/15/15	15/15/15
Feedrate	Max cutting feedrate(M/min)	10	10	10
Spindle	Spindle speed/rpm	60-8000	60-8000	60-8000
	Spindle taper/spindle shank	7:24 Taper No.40	7:24 Taper No.40	7:24 Taper No.40
	Max spindle inner diameter/mm	Φ60	Φ60	Φ70
	Spindle motor(30 mins,mitsubishi)/kw	3	5.5	7.5
Accuracy	Positioning accuracy/mm	±0.005	±0.01	±0.01
Accuracy	Repeatability positioning accuracy/mm	±0.003	±0.005	±0.005
Machine size	Machine height/mm	1800	2260	2330
	Space requirement(L*W)	2200*2000	2500*1870	2560*2300
	Net machine weight/kg	2000	3000	4500
	Power requirement/KVA	10	10	15
	Drive motor/kw	1./1.0/1.0	1./1.0/1.0	1.5/1.5/1.5
	Control system	Snytec or HNC	Snytec or HNC	Snytec or HNC
Worktable	Table size/(L*W)	600*300	600*360	700*450
	Max load on the table/kg	300	300	400
	T-slot size/mm	183105	183110	183110

china cnc milling machine Main machine configuration	1. China cnc milling machine control system: Syntec EZ4 controller From Taiwan. HNC servo motor;
	2. frequency-changing spindle,6000rpm, 7/24 Taper No.40;
	3. fully enclosed splash guard;
	4. pneumatic cylinder for unclamp tools;
	5. screw rod chip removal system;
	6. metal sheet cover for guide rail;
	7. work and alert lamps
	8. cooling system and water tank
	9. heat exchanger
	10. auto lubrication system;
	11. 380/220v 50Hz transformer.
	12.High speed bearing.
	13.China cnc milling machine with 4th NC indexing head FK15145
