| Model No. |
GL-3460 |
GL-3480 |
| Capacity |
X axis travel/mm |
6200 |
8200 |
| Y axis travel/mm |
4000 |
4000 |
| Z axis travel/mm |
1250 |
1250 |
| Spindle nose to worktable/mm |
310-1310 |
| Worktable |
Table size(L*W) |
6000*2600 |
8000*2600 |
| Gate width/mm |
3400 |
3400 |
| T-slot(width*numbers*span) |
28*200(translot) |
| Max load on the table/T |
25 |
30 |
| spindle |
Spindle speed/rpm |
ZF two speed gearbox(1:1/1:4)/6000(4000) |
| Spindle taper |
7/24 Taper No.50 |
| Spindle motor/kw |
15/18.5 |
| Feedrate |
X,Y axis rapid traverse(M/min) |
10 |
10 |
| Z axis rapid traverse(M/min) |
10 |
10 |
| Max cutting feedrate(mm/min) |
100-7000 |
| A.T.C |
Toolmagazine capacity(opt)/pc |
20/24/32/40/60 |
| Optional |
Max exterior tool diameter/mm |
φ200 |
| |
Max tool length/mm |
350 |
| |
Max tool weight/kg |
20 |
| |
Tool change time/sec(T-T) |
3.5 |
| Accuracy |
Axis positioning accuracy/mm |
0.025<5000 |
| Axis repeatability positioning accuracy/mm |
0.015 |
| Machine size |
Power requirement/KVA |
40 |
| Space requirement (L×W) |
15000*7500 |
19000*7500 |
| Machine height/mm |
6250 |
6250 |
| Machine weight(T) |
92 |
105 |
| Control system |
FANUC |
